    SY5882 样品申请
    概述

    The SY5882 is a power management IC (PMIC) designed for notebook, desktop, and embedded computing platforms. There are three DCDC converters and two linear regulators integrated into the SY5882, which can minimize the need for external components so that it can ease the layout in a constrained PCB area. The DCDC converters are of high accuracy, high efficiency, and high flexibility. Two LDOs provide power rails for peripherals and pull-up resistors.
    The SY5882 provides protection for a device when a fault occurs, such as overcurrent, output overvoltage, output undervoltage, short circuit, input overvoltage, and over temperature.
    The SY5882 is a halogen- and lead-free device, compliant with RoHS. The package is QFN3x3-20.

    产品特性

    AVIN input supply range: 2.7V to 5.5V

    Three buck regulators: BUCK1,output range 1.7V ~ 3.3V; BUCK2,output range 0.9V ~ 2.0V; BUCK3,output range 0.5V ~ 1.3V

    2 linear regulators: LDO1, 1V ~ 3.3V, 50mV/Step, 0.4A;  LDO2, 1V ~ 3.3V, 50mV/Step, 0.4A

    DCDC voltage accuracy:±1% FB Voltage

    BUCK1 can be set as load switch

    LDO1/LDO2 can be set as load switch

    Configurable Soft-start Time for All output

    Configurable power on sequence

    Configurable sleep and wake-up sequence

    I2C Interface 400kHz/1MHz

    Built-in AVIN OV/UV warning indication and fault protection

    Built-in VOUT OVP/UVP/OCL

    Built-in Overd Temperature Protection

    Built-in EFUSE for configurable default value of registers

    3 multifunctional ioses

    产品参考应用图
    应用

    Solid-state drive

    Video system
